機種 / 重量 |
|
直立型 |
|
TY - 203 約 97 kg |
|
TY - 223 約200kg |
|
TY - 231 約250kg |
|
 |
 |
 |
|
|
|
|
|
|
|
 |
| |
|
|
橫 型 |
|
TY - 204 約 50 kg |
|
TY - 224 約103kg |
|
TY - 232 約125kg |
|
|
|
|
|
|
|
|
|
|
|
|
| |
主軸衝程 最大mm |
|
|
|
45 mm |
|
65 mm |
|
65 mm |
|
|
|
|
|
|
|
|
|
|
|
|
| |
旋徑 mm |
|
|
|
330 |
|
430 |
|
460 |
|
|
|
|
|
|
|
|
|
|
|
|
| |
螺牙直徑 鉆孔能力 mm |
|
|
|
2 ~8以下(10) |
|
5~16 |
|
10~32 |
|
|
|
|
|
|
|
|
|
|
|
|
| |
頭部之上下動距 mm |
|
|
|
260 |
|
300 |
|
450 |
|
|
|
|
|
|
|
|
|
|
|
|
| |
主軸端和台之距離 最大mm |
|
|
|
350 |
|
470 |
|
600 |
|
|
|
|
|
|
|
|
|
|
|
|
| |
工作台尺寸 |
|
|
|
225 * 230 |
|
340 * 340 |
|
340 * 380 |
|
|
|
|
|
|
|
|
|
|
|
|
| |
基礎面積 mm |
|
|
|
415 * 300 |
|
600* 420 |
|
600* 420 |
|
|
|
|
|
|
|
|
|
|
|
|
| |
馬達 |
|
|
|
3相 , 4p ,
400w |
|
3相 , 6p ,
750w |
|
3相 , 6p ,
1.5kw |
|
|
|
|
|
|
|
|
|
|
|
|
| |
主軸迴轉數 |
|
50HZ |
|
1340 , 760 , 420 |
|
515 , 285, 155 |
|
200 , 100 , 50 |
|
|
 |
|
|
|
|
|
|
|
|
| |
|
60HZ |
|
1600 , 900 , 500 |
|
620 , 340, 190 |
|
240 , 120, 60 |
|
|
|
|
|
|
|
|
|
|
|
|
| |
符合本機器使用之自動送給螺距：每部機器都裝有一個交換齒輪,如上表規格均能使用 |
|
每英寸
的牙數 |
|
64 , 56 , 48 , 44
40 , 32 , 28 , 24
20 , 18 , 16 |
|
28 , 24, 20, 19
18 , 16, 14, 12
11 , 10 |
|
19 , 16 , 14
12 , 11, 10
9 , 8 |
|
|
|
|
|
|
|
|
|
|
|
| |
|
mm |
|
0.2,0.25,0.3,0.35,0.4
0.45,0.5,0.6,0.7,0.75
0.8,0.9,1.0,1.25(1.5) |
|
0.7,0.8,0.9,1.0
1.25,1.5,1.75
1.8,2.0,2.5 |
|
1.5 , 1.75
2.0 , 2.5
3.0 , 3.5 |
|
|
|
|
|
|
|
|
|
|
|
|
 |
|
 |
|
|
|
|
|
|
|
 |
|
|
|
|
|
